12mm Non-perforated Worm Gear Hose Clamp

12mm Worm drive hose clamp, also called German type hose clamp with welding housing, which is a highly reliable and commonly used fastening device in various industries.Band is non-perforated, it is used for heavy equipment, recreational vehicles, lawn and garden equipment.

Description

Structure Diagram

Feature

Simple appearance, smooth lines, smooth and even hoop parts
The band is a non-perforated design, which can protect the surface of the hose from damage and avoid hose wear and rupture caused by perforation
Band Width: 9mm
Band Thickness: 0.6mm/0.7mm
Screw: 7mm Hex slotted or cross screw head
Free/Loading Torque: ≤1N.m/≥6.5N.m
Connecting way: Welding
Material and tightening range are printed on the steel belt.
Standard: BSPT
Application: For heavy equipment, recreational vehicles, lawn and garden equipment

Parameters

Size(mm)	Width(mm)	UD NO.	PCS/Bag	Pcs/CTN
12-20	12	12UDGT1220	100	1000
16-27	12	12UDGT1627	100	1000
20-32	12	12UDGT2032	100	1000
25-40	12	12UDGT2540	100	1000
30-45	12	12UDGT3045	50	500
32-50	12	12UDGT3250	50	500
40-60	12	12UDGT4060	50	500
50-70	12	12UDGT5070	50	500
60-80	12	12UDGT6080	20	500
70-90	12	12UDGT7090	20	500
80-100	12	12UDGT80100	20	500
90-110	12	12UDGT90110	20	500
100-120	12	12UDGT100120	20	500
110-130	12	12UDGT110130	20	500
120-140	12	12UDGT120140	20	250
130-150	12	12UDGT130150	20	250
140-160	12	12UDGT140160	20	250
…….
Sizes can be adjusted as per inquiry.

Material

Material	Band	Housing	Screw
W1	Zinc plated steel	Zinc plated steel	Zinc plated steel
W2	AISI 201SS/304SS	AISI 201SS/304SS	Zinc plated steel
W4	AISI 201SS/304SS	AISI 201SS/304SS	AISI 201SS/304SS
W5	AISI 316SS	AISI 316SS	AISI 316SS
